KL-CME-GM-A114

KL-CME-GM-A114 is a heavy-duty, high-performance geared elevator motor engineered for demanding lift systems. Designed to deliver high torque, exceptional mechanical stability, and smooth operation at elevated speeds, it is ideal for commercial buildings, high-traffic towers, and modernization projects requiring maximum traction performance.

With a 1:1 suspension system, Ø580–700 mm pulley options, and reinforced traction components, the KL-CME-GM-A114 provides consistent performance under heavy loads and continuous duty cycles.

Performance Variations

The KL-CME-GM-A114 machine group supports a wide performance range, suitable for medium-to-high-speed elevators:

• Capacity range: 960 – 3680 kg

• Speed range: 1.00 – 3.20 m/s

• Power range:

  • 11.00 kW (14.96 HP)

  • 15.00 kW (20.40 HP)

  • 18.50 kW (25.16 HP)

  • 22.00 kW (29.92 HP)

  • 10.30–14.71 kW special low-speed versions

• Operating current: 23 – 44.2 A

• Pulley diameter: Ø580 – Ø700 mm

• Rope count: 6 – 10 ropes

• Rope diameter: Ø10 – Ø14 mm

• Static load capacity: 12000 kg

• Travel height: 51 m / 33 m

This broad configuration portfolio allows the KL-CME-GM-A114 to address heavy-capacity and mid-rise high-speed lift requirements.

General Technical Features

• Car Speed Options: 1.00 / 1.20 / 1.60 / 2.00 / 2.40 / 3.20 m/s

• Suspension Type: 1:1

• Pulley Diameter: Ø580 / Ø700 mm

• Rope Number: 6–10

• Rope Diameter: Ø10–14 mm

• Static Load Capacity: 12000 kg

• Travel Heights: 51 m and 33 m

• High-strength cast traction components

• Low-noise, low-vibration gearbox

• High torque for demanding high-load elevator groups

• Long-life bearings and durable brake system

• Suitable for continuous commercial operation

• Optimized for stable temperature and vibration control

The KL-CME-GM-A114 ensures smooth ride comfort, consistent torque delivery, and superior traction even at maximum load levels.

Certifications & Compliance

The KL-CME-GM-A114 is manufactured in accordance with major international standards:

• CE Declaration

• TSEK compliance for geared elevator machinery

• A3 brake safety certification

• ISO 9001:2015 Quality Management

• ISO 50001:2018 Energy Management

• EMC compliance

• Registered design conformity for traction systems

These certifications ensure global compatibility, long-term safety, and stable operation in commercial applications.

Applications

• High-capacity commercial buildings

• Heavy-traffic residential towers

• Mid-rise and high-speed elevator systems

• Modernization projects requiring increased torque

• Standard machine-room installations

Key Advantages

• Powerful traction for heavy-duty elevator groups

• Wide capacity and speed range

• Superior ride comfort and low vibration

• High static load strength (12000 kg)

• Long service life under continuous operation

• Broad modernization compatibility

• Robust gearbox structure for heavy-duty cycles
